About this item

• Fast Marking: The marking machine adopts full 32-bit DSP technology, uses H-bridge drive mainboard, and integrated circuits can achieve industrial-grade response speed and chopping frequency, quickly completing marking (2in/s). The third-generation electromagnetic needle controller maintains stable and high-quality pulses, significantly reducing the risk of combustion. It effectively ensures the safe and stable operation of the equipment.
• Wide Compatibility: Equipped with the upgraded X9 software, it is widely compatible with multiple operating systems such as XP, Win7, Win8, Win9, and Win10. It features an industrial-grade 400W pure copper motor with low working noise. Made of high-quality aluminum alloy and cold-rolled steel plates through die-casting process, it maintains both beauty and practicality for a long time.
• Precise Marking: The gantry structure effectively resolves the displacement and vibration issues that may occur during operation, ensuring accurate and consistent marking results and improving the quality of each marking. The 96HRA marking needle has high hardness and good wear resistance, and is suitable for materials of various hardness.
• Thoughtful Design: Adjustable marking range, depth and speed, capable of handling delicate or harder products of different sizes and shapes. The automatic memory function can automatically generate serial flow marking numbers. The electric marking method does not require an air compressor (air pump), greatly saving your time and energy.
• Widely Used: It can be used to mark fixed characters, serial numbers, vin, dates, graphics, etc. on various metal materials such as aluminum, stainless steel, copper and iron.

Specification

Material: Aluminum Alloy, Cold-rolled Plate

Treatment Process: Die-casting

Motor: Pure Copper Motor

Control Method: Computer (Excluded) + Knob + Buttons

Plug: US Plug

Voltage: 110V

Power: 400W

Needle Hardness: 96HRA

Marking Depth: 0.05-1mm

Needle Distance: 0.5-1mm

Marking Speed: 50mm/s (2in/s)

Marking Scope: 200*150mm/7.9*5.9in

Maximum Lifting Height: 15mm/0.6in

Product Size: 36*35.5*30cm/14.2*14*11.8in

Package Size: 45.3*46*38cm/17.8*18.1*15in

Net Weight: 12.65kg/27.9lbs

Gross Weight: 15.55kg/34.3lbs

Package Included

1* Electric Metal Marking Machine

1* Power Cord

1* USB Flash Disk

2* English Manuals

All Accessories for Assembly
